Backyard Discovery HILLCREST - Page 69

STEP 40 - FORT ASSEMBLY
QTY
PART NUMBER
DESCRIPTION
2
H100010
BOLT WH 5/16x1 1/2
2 H100028 LAG SCREW WH 5/16x2 1/2
4
H100030
WASHER LOCK EXT 8x19
2 H100074 T-NUT 5/16
PICNIC SEAT SUPPORT - W4L16050
5/8"x3 3/8"x22" (16x86x558)
M14
(x2)
M14 (x2)
028 (x2)
LAG SCREW - 2 1/2"
010 (x2)
BOLT - 1 1/2"
030 (x4)
WASHER - 8x19
074 (x2)
T-NUT - 5/16"
69
