STEP 41 - FORT ASSEMBLY
QTY
PART NUMBER
DESCRIPTION
2
H100009
BOLT WH 5/16x1 1/4
2 H100010 BOLT WH 5/16x1 1/2
2
H100028
LAG SCREW WH 5/16x2 1/2
6 H100030 WASHER LOCK EXT 8x19
4 H100074 T-NUT 5/16
TABLE SUPPORT - W4L16031
1"x3 3/8"x12" (24x86x306)
H08
(x2)
TABLE SUPPORT - W4L16037
5/8"x3 3/8"x13 1/2" (16x86x342)
M25
(x2)
H08 (x2)
009 (x2)
BOLT - 1 1/4"
010 (x2)
BOLT - 1 1/2"
074 (x4)
T-NUT - 5/16"
030 (x6)
WASHER - 8x19
028 (x2)
LAG SCREW - 2 1/2"
M25 (x1)
M25 (x1)
TIP:
INSTALL T-NUTS IN WOOD FIRST
