Backyard Discovery MALIBU - Page 109

STEP 61
FRONT
E10
T-NUT 5/16 BLK
(2 PLCS)
BOLT WH 5/16x2-1/4 BLK
(2 PLCS)
WASHER LOCK EXT 8x19 BLK
(2 PLCS)
NOTE HOLE LOCATION FOR
PROPER INSTALLATION.
BOLT WH
5/16x2-1/4
BLK
(2)
T-NUT 5/16
BLK
(2)
WASHER
LOCK EXT
8x19 BLK
(2)
E10 - FORT UPRIGHT - W4L06455
1 3/8"x3 3/8"x51 3/8" (36x86x1305)

109
