STEP 62
SCREW PFH 8x1 1/2
(6 PLCS)
NOTE HOLE LOCATION FOR
PROPER INSTALLATION.
SCREW PFH
8x1 1/2
(6)
M11
M11
M11 - FRONT CORNER BOARD - W4L06446
5/8"x3 3/8"x45 3/4" (16x86x1163)

110
