Backyard Discovery MALIBU - Page 118

STEP 70
FRONT
WASHER
LOCK EXT
8x19 BLK
(6)
LAG SCREW WH 5/16x1 1/2 BLK
(2 PLCS)
WASHER LOCK EXT 8x19 BLK
(2 PLCS)
T-NUT 5/16 BLK
(4 PLCS)
WASHER LOCK EXT 8x19 BLK
(4 PLCS)
BOLT WH 5/16x1 3/4 BLK
(4 PLCS)
M18
M18
M17
LAG SCREW
WH 5/16x1 1/2
BLK
(2)
BOLT WH
5/16x1 3/4
BLK
(4)
T-NUT 5/16
BLK
(4)
M17 - WALL RAIL - W4L06459
5/8"x3 3/8"x26 5/8" (16x86x676)

M18 - WALL RAIL - W4L06461
5/8"x3 3/8"x25 7/8" (16x86x658)

118
