Backyard Discovery MALIBU - Ground Stakes for Stability

STEP 111
KC - METAL GROUND STAKE BROWN - A100178

BOLT WH 1/4x1/2 BLK
(2 PLCS)
WASHER FLAT 9x18 BLK
(2 PLCS)
WASHER LOCK EXT 8x15 BLK
(2 PLCS)
NUT BARREL WH 1/4x7/8 BLK
(2 PLCS)
2 5/8"
28 1/8"
METAL GROUND STAKE BROWN
(2 PLCS)
BOLT WH
1/4x1/2 BLK
(2)
WASHER
FLAT 9x18
BLK
(2)
WASHER
LOCK EXT
8x15 BLK
(2)
NUT BARREL
WH 1/4x7/8
BLK
(2)
DRILL THROUGH USING
A 5/16" DRILL BIT.
NOTE:
FAILURE TO USE GROUND STAKES CAN
VOID WARRANTY & CAUSE INJURY!
NOTE:
TWIST STAKES INTO
GROUND AND ATTACH
TO PLAYSET
APPROXIMATELY
WHERE SHOWN.
159
