Backyard Discovery MALIBU - Final Tightening and Leveling

STEP 113
KC - METAL GROUND STAKE BROWN - A100178

WASHER
FLAT 9x18
BLK
(2)
WASHER
LOCK EXT
8x15 BLK
(2)
NUT BARREL
WH 1/4x5/8
BLK
(2)
BOLT WH
1/4x1 BLK
(2 PLCS)
WASHER FLAT
9x18 BLK
(2 PLCS)
NUT BARREL
WH 1/4x5/8 BLK
(2 PLCS)
WASHER LOCK
EXT 8x15 BLK
(2 PLCS)
2 5/8" TYP
9 1/2" 9 1/2"
DRILL THROUGH USING
A 5/16" DRILL BIT.
METAL GROUND STAKE BROWN
(2 PLCS)
FINAL STEP
DOUBLE CHECK EVERY BOLT, SCREW AND
NUT FOR TIGHTNESS. MAKE SURE EVERY
BOARD IS SECURE AND MAKE SURE THE
PLAY SET IS LEVEL.
ENJOY YOUR NEW PLAY SET!
