Backyard Discovery MALIBU - Swing Beam and Glider Assembly; 5 Ft Swing Beam Assembly

STEP 1
5 FT SWING BEAM ASSEMBLY
BOLT HEX
5/16x4 1/4
BLK
(2)
BOLT WH
5/16x3 BLK
(3)
NUT BARREL
WH 5/16x7/8
BLK
(3)
WASHER
FLAT 8x27
BLK
(4)
WASHER
SPLIT 5/16
BLK
(2)
NUT LOCK
5/16 BLK
(2)
A50 - SWING BEAM - W4L06616
3 3/8"x5 1/4"x89 1/2" (86x134x2274)

TC - SWING BEAM EXTENSION BRACKET-RIGHT - A100326

TB - SWING BEAM EXTENSION BRACKET-LEFT - A100325

GD - L BRACKET 66x66x127 - A100140

BOLT HEX 5/16x4 1/4 BLK
(2 PLCS)
WASHER SPLIT 5/16 BLK
(2 PLCS)
WASHER FLAT 8x27 BLK
(2 PLCS)
WASHER FLAT 8x27 BLK
(2 PLCS)
NUT LOCK 5/16 BLK
(2 PLCS)
BOLT WH 5/16x3 BLK
(3 PLCS)
NUT BARREL WH 5/16x7/8 BLK
(3 PLCS)
A50
GD
TB
TC
39
