Backyard Discovery MALIBU - Slide Assembly; Slide Rail and Bed Assembly

TOP
BOTTOM
TIP: PREBENDING THE ENDS WILL EASE ASSEMBLY.
USE M70 SLIDE BED SUPPORT AS A
TEMPLATE FOR DRILLING BOTTOM
HOLE PATTERN IN SLIDE BED. BE SURE
TO PLACE SLIDE BRACE UP 1/2" FROM
BOTTOM EDGE OF SLIDE BED BEFORE
MARKING HOLE PATTERN. USE A 3/8"
DRILL BIT TO DRILL HOLE PATTERN.

SLIDE ASSEMBLY
STEP 1
(SEE SLIDE ASSEMBLY
INSTALLATION STEP FOR
DECK MOUNTING HOLE
DRILLING LOCATIONS).
SLIDE BED 10' YELLOW
3/&
BOLT WH
5/16x1/2
(3)
KE - SLIDE BED 10' YELLOW - A100197

M70 - SLIDE BED SUPPORT - W100935
5/8"x3 3/8"x19 7/8" (16x86x505)

0
BOLT WH 5/16x1/2
3/&6
T-NUT 5/16
3/&6
T-NUT 5/16
(3)
45
