STEP 30
FRONT
LEFT BACK
RIGHT
SCREW PFH
8x1 1/4
(2)
SCREW PFH 8x1 1/4
(2 PLCS)
FLUSH SURFACES
N3
N3 - LEFT WINDOW SHELF - W4L06415
5/8"x2 3/8"x19 1/8" (16x60x485)

78
