STEP 31
FRONT
LEFT
BACK
RIGHT
SCREW PFH
8x1 1/4
(2)
SCREW PFH 8x1 1/4
(2 PLCS)
N2
FLUSH SURFACES
N2 - REAR WINDOW SHELF - W4L06414
5/8"x2 3/8"x18 7/8" (16x60x479)

79
