Parts Identification
Wood Components
(NOT TO SCALE)
K9 - LEFT BALCONY WALL RAIL - W4L07500
5/8"x5 1/4"x20 3/4" (16x134x528)

K10 - FRONT BALCONY WALL RAIL - W4L07501
5/8"x5 1/4"x40 5/8" (16x134x1032)

K11 - LEFT SIDE WALL BOARD - W4L07508
5/8"x5 1/4"x41 7/8" (16x134x1064)

K12 - ARCHED WALL RAIL - W4L07579
5/8"x5 1/4"x40 5/8" (16x134x1032)

K13 - ARCHED WALL RAIL - W4L07580
5/8"x5 1/4"x40 5/8" (16x134x1032)

K14 - ANGLED WALL RAIL - W4L07581
5/8"x5 1/4"x45 3/4" (16x134x1162)

K15 - ANGLED WALL RAIL - W4L07582
5/8"x5 1/4"x45 3/4" (16x134x1162)

K16 - TABLE BOARD - W4L07594
5/8"x5 1/4"x23" (16x134x583)

K17 - FLOOR BOARD - W4L07596
5/8"x5 1/4"x21 1/8" (16x134x537)

