Backyard Discovery Mount Triumph - Page 40

SWING BEAM ASSEMBLY
STEP 2
BOLT WH 5/16x2 BLK
(2 PLCS)
WASHER LOCK EXT 8x19 BLK
(2 PLCS)
WASHER LOCK EXT 12x19 BLK
(2 PLCS)
NUT BARREL WH 5/16x7/8 BLK
(2 PLCS)
BOLT WH 5/16x2 BLK
(2 PLCS)
WASHER LOCK EXT 8x19 BLK
(2 PLCS)
WASHER LOCK EXT 12x19 BLK
(2 PLCS)
NUT BARREL WH 5/16x7/8 BLK
(2 PLCS)
LAG SCREW WH 5/16x2 BLK
(2 PLCS)
WASHER LOCK EXT 8x19 BLK
(2 PLCS)
BOLT WH 5/16x4 1/2 BLK
(1 PLC)
WASHER LOCK EXT 8x19 BLK
(1 PLC)
NUT BARREL WH 5/16x7/8 BLK
(1 PLC)
WASHER LOCK EXT 12x19 BLK
(1 PLC)
H80 - GROUND BOARD - W4L07630
1"x3 3/8"x87 3/8" (24x86x2218)

E77 - ANGLE BRACE - W4L07631
1 3/8"x3 3/8"x74 3/8" (36x86x1890)

H79 - END SUPPORT - W4L07632
1"x3 1/2"x42" (24x86x1072)

W71 - SWING BEAM SUPPORT - W4L07629
2"x3 3/8"x49 5/8" (50x86x1260)

W71
E77
H79
H80
E77
NUT BARREL
WH 5/16x7/8
BLK
(5)
WASHER
LOCK EXT
12x19 BLK
(5)
WASHER
LOCK EXT
8x19 BLK
(7)
BOLT WH
5/16x4 1/2
BLK
(1)
BOLT WH
5/16x2 BLK
(4)
LAG SCREW
WH 5/16x2
BLK
(2)
