Backyard Discovery Mount Triumph - Page 41

SWING BEAM ASSEMBLY
STEP 3
BOLT WH 5/16x1 3/4 BLK
(2 PLCS)
BOLT WH 5/16x2-1/2 BLK
(2 PLCS)
WASHER LOCK EXT 8x19 BLK
(2 PLCS)
NUT BARREL WH 5/16x7/8 BLK
(2 PLCS)
WASHER LOCK EXT 12x19 BLK
(2 PLCS)
NUT BARREL WH 5/16x1-1/2 BLK
(2 PLCS)
BOLT WH
5/16x1 3/4
BLK
(2)
NUT BARREL
WH 5/16x7/8
BLK
(2)
WASHER
LOCK EXT
8x19 BLK
(2)
WASHER
LOCK EXT
12x19 BLK
(2)
BOLT WH
5/16x2-1/2
BLK
(2)
NUT BARREL
WH 5/16x1-1/2
BLK
(2)
40
