Backyard Discovery Mount Triumph - Page 51

STEP 5
WASHER
LOCK EXT
8x19 BLK
(3)
LAG SCREW
WH 5/16x1 1/2
BLK
(3)
LAG SCREW WH 5/16x1 1/2 BLK
(2 PLCS)
WASHER LOCK EXT 8x19 BLK
(2 PLCS)
L BRACKET BLACK 32x51
LAG SCREW WH 5/16x2 BLK
(1 PLC)
LAG SCREW WH 5/16x1 1/2 BLK
(1 PLC)
WASHER LOCK EXT 8x19 BLK
(1 PLC)
L4
L2
LAG SCREW
WH 5/16x2
BLK
(1)
- L BRACKET BLACK 32x51 - A4M00710
(1)
L2 - WALL RAIL - W4L07515
5/8"x4 3/8"x22 7/8" (16x112x582)

L4 - ARCHED WALL RAIL - W4L07577
5/8"x4 3/8"x43 1/2" (16x112x1106)

