Backyard Discovery Mount Triumph - Page 55

STEP 9
INSTALL T-NUTS INTO PARTS BEFORE ASSEMBLY OF
PARTS.
WASHER
LOCK EXT
8x19 BLK
(10)
T-NUT 5/16 BLK
(10 PLCS)
WASHER LOCK EXT 8x19 BLK
(2 PLCS)
BOLT WH 5/16x2-1/4 BLK
(2 PLCS)
WASHER LOCK EXT 8x19 BLK
(4 PLCS)
BOLT WH 5/16x2 BLK
(4 PLCS)
WASHER LOCK EXT 8x19 BLK
(2 PLCS)
BOLT WH 5/16x2 BLK
(2 PLCS)
WASHER LOCK EXT 8x19 BLK
(2 PLCS)
BOLT WH 5/16x2 BLK
(2 PLCS)
E11
E5
BOLT WH
5/16x2 BLK
(8)
BOLT WH
5/16x2-1/4
BLK
(2)
T-NUT 5/16
BLK
(10)
E5 - RIGHT FRONT BALCONY UPRIGHT - W4L07502
1 3/8"x3 3/8"x80 3/4" (36x86x2052)

SCREW PFH 8x1-1/2 BLK
(4 PLCS)
E11 - RIGHT FRONT BALCONY UPRIGHT - W4L07673
1 3/8"x3 3/8"x80 3/4" (36x86x2052)

N1 - PORCH GROUND BOARD - W4L07503
5/8"x2 3/8"x21 1/8" (16x60x537)

N1
S
C
R
E
W
P
F
H
8
x
1
-
1
/
2
B
L
K
(
4
)
PILOT HOLE OUT.
54
