STEP 8
NUT BARREL WH 5/16x5/8 BLK
(2 PLCS)
WASHER LOCK EXT 12x19 BLK
(2 PLCS)
BOLT WH 5/16x1/2 BLK
(2 PLCS)
L3
K9
NUT BARREL
WH 5/16x5/8
BLK
(2)
BOLT WH
5/16x1/2 BLK
(2)
WASHER
LOCK EXT
12x19 BLK
(2)
L3 - WALL RAIL - W4L07576
5/8"x4 3/8"x20 7/8" (16x112x529)

K9 - LEFT BALCONY WALL RAIL - W4L07500
5/8"x5 1/4"x20 3/4" (16x134x528)

53
