STEP 15
SCREW PFH
8x1 1/2
(18)
M10
M11
SCREW PFH 8x1 1/2
(18 PLCS)
M10 - FLOOR BOARD - W4L07609
5/8"x3 3/8"x40 5/8" (16x86x1031)

M11 - FLOOR BOARD - W4L07610
5/8"x3 3/8"x40 5/8" (16x86x1031)

60
