Backyard Discovery Mount Triumph - Page 62

STEP 16
TOP VIEW
T2
T1
SCREW PFH 8x1 1/4 BLK
(3 PLCS)
SCREW PFH 8x1 1/2
(3 PLCS)
SCREW PFH
8x1 1/2
(3)
SCREW PFH
8x1 1/4 BLK
(3)
T1 - SUPPORT BOARD - W4L07599
1"x1 3/8"x37 5/8" (24x34x957)

T2 - SUPPORT BOARD - W4L07600
1"x1 3/8"x37 3/4" (24x34x959)

49 mm [1 7/8 in]
BOTH SUPPORTS
