STEP 17
SCREW PFH 8x1 1/2
(24 PLCS)
SCREW PFH
8x1 1/2
(24)
M8
M13
M9
M8 - FLOOR BOARD - W4L07607
5/8"x3 3/8"x20 1/8" (16x86x512)

M9 - FLOOR BOARD - W4L07608
5/8"x3 3/8"x20 1/8" (16x86x512)

M13 - FLOOR BOARD - W4L07671
5/8"x3 3/8"x20 1/8" (16x86x512)

62
