STEP 26
9
0
m
m
[
3
1
/
2
i
n
]
WP2
SCREW PFH 8x1 1/4 BLK
(4 PLCS)
SCREW PFH 8x1 1/4 BLK
(4 PLCS)
SCREW PFH
8x1 1/4 BLK
(8)
(2)
WP2 - RIGHT LOWER WALL PANEL - W2A02083
1"x16 7/8"x46 1/2" (24x430x1181)
