Backyard Discovery Mount Triumph - Page 87

AH
STEP 41
FRONT PICKET PLACEMENT
LEFT & RIGHT PICKET PLACEMENT
SCREW PFH
8x1 1/8
(40)
SCREW PFH 8x1 1/8
(40 PLCS)
51 mm [2 in]
TYP
60 mm [2 3/8 in]
(4 SPCS)
N2 - PICKET - W4L07612
5/8"x2 3/8"x24 3/4" (16x60x628)

86
