STEP 45
SCREW PFH
8x1 3/4
(8)
SCREW PFH 8x1 3/4
(8 PLCS)
(2)
RP1 - BOTTOM ROOF PANEL - W2A02092
1 3/8"x48"x19 3/8" (35x1220x491)
RP1
RP1
90
