Backyard Discovery Mount Triumph - Page 92

STEP 46
E10
SCREW PFH 8x1 1/4 BLK
(2 PLCS)
STEERING WHEEL
WASHER FLAT 8x27
(INCLUDED IN KIT)
LAG SCREW WH 5/16x1 1/2
(INCLUDED IN KIT)
PLASTIC CAP
(INCLUDED IN KIT)
SCREW PFH
8x1 1/4 BLK
(2)
NOTE HOLE LOCATION
FOR PROPER ORIENTATION.
LP - STEERING WHEEL - A100105
(1)
E10 - MOUNTING BLOCK - W4L07615
1 3/8"x3"x4 3/4" (36x76x120)

91
