Backyard Discovery SOMERVILLE - Step 5: Installing Slotted Joists

NOTES:
LOCATE AND USE PILOT HOLES IN
THE OUTER JOISTS TO MOUNT D13
BOARDS AS SHOWN.
204 (x1)
LAG SCREW - 5 1/2"
198 (x1)
WASHER - 8x19
D13 (x8)
SLOTTED JOIST
LAG SCREW WH BLK
5/16x5 1/2
(x16)
H100204
WASHER LOCK EXT BLK
8x19
(x16)
H100198
SLOTTED JOIST - W4L13789
1 3/8"x5 1/4"x114" (36x134x2896)
D13
(x8)
STEP 5
REPEAT ON OPPOSITE END AND ON ALL JOISTS
21
