Backyard Discovery SOMERVILLE - Step 9: Anchoring Feet to Concrete

NOTES:
STEP 9
120 (x4)
SCREW - 2"
SCREW CONCRETE ANCHOR
1/4x2
(x16)
H100120
CHALK LINE
MOVE THE PERGOLA ASIDE AND PLACE EACH FOOT INSIDE THE LINES DRAWN IN THE
PREVIOUS STEP. NOW, USE A 3/16" CONCRETE DRILL BIT TO DRILL PILOT HOLES INTO
THE CONCRETE PAD.
NEXT, USE THE PROVIDED CONCRETE ANCHORS TO ATTACH EACH FOOT TO THE
CONCRETE SURFACE.
REPEAT ON ALL FEET
25
