PM
OV x3
22-1/4"
(57 cm)
22-1/4"
(57 cm)
(117,5 cm)
1-1/2"
(3,8 cm)
1-1/2"
(3,8 cm)
49-1/2"
(125,7 cm)
24-3/4"
(63 cm)
24-3/4"
(63 cm)
36
SIDE WALL FRAMES
1
2
If building 10' x 8' kit orient parts on edge on oor.
Measure and mark from end of boards.
If building 10' x 12' kit, go to page 38. If building 10' x 16' kit, go to page 42.
IMPORTANT! You will build (2) identical walls.
Secure with (2) 3" nails
at each mark.
3" (7,6 cm)
PARTS REQUIRED:
x6
2 x 3 x 69" (5 x 7,6 x 175 cm)
x4
7/16 x 2-1/2 x 24-3/4" (1,1 x 6,4 x 62,9 cm)
OV
x2
2 x 3 x 92-5/8" (5 x 7,6 x 235,3 cm)
PM
x14
DOOR
Center on marks.
HINT:
3" (7,6 cm) Nails
To Next Page
