Backyard Products GABLE - 10 x 16 SIDE WALL FRAMES ASSEMBLY; PARTS REQUIRED FOR 10 x16 SIDE WALL FRAMES; ASSEMBLING 10 x16 SIDE WALL FRAMES

PM
OV x7
NK NK
22-1/4"
(57 cm)
24"
(61 cm)
24"
(61 cm)
22-1/4"
(57 cm)
24"
(61 cm)
24"
(61 cm)
24"
(61 cm)
24"
(61 cm)
1-1/2"
(3,8 cm)
1-1/2"
(3,8 cm)
48-3/4"
(123,8 cm)
24-3/4"
(63 cm)
48"
(122 cm)
48-3/4"
(123,8 cm)
48"
(122 cm)
145-1/2"
(369,6 cm)
24-3/4"
(63 cm)
188-1/2"
(478,8 cm)
166-1/4"
(422,3 cm)
142-1/4"
(361,3 cm)
118-1/4"
(300,5 cm)
94-1/4"
(239,4 cm)
70-1/4"
(178,4 cm)
46-1/4"
(117,5 cm)
48"
(122 cm)
DOOR
44
10' x 16' SIDE WALL FRAMES
1
BEGIN
Measure and mark from end of boards.
IMPORTANT! You will build (2) walls the same.
Secure with (2) 3" nails at each mark.
3" (7,6 cm)
PARTS REQUIRED:
x6
x2
2 x 3 x 69" (5 x 7,6 x 175 cm)
2 x 3 x 48" (5 x 7,6 x 122 cm)
x4
x4
7/16 x 2-1/2 x 24-3/4" (1,1 x 6,4 x 62,9 cm)
7/16 x 2-1/2 x 48" (1,1 x 6,4 x 122 cm)
OV
NK
x2
2 x 3 x 92-5/8" (5 x 7,6 x 235,3 cm)
PM
x84
Center
on marks
3" (7,6 cm)
Nails
HINT:
