Backyard Products GABLE - DOOR TRIM INSTALLATION; PARTS REQUIRED FOR DOOR TRIM; INSTALLING DOOR TRIM

ZZ
DOOR TRIM
DOOR
ZZ
FINISH
3
PARTS REQUIRED:
5/8 x 3 x 14" (1,6 x 7,6 x 35,5 cm)
x8
x16
3/4" (19 mm)
BEGIN
Position parts on lower pane of Door Panel, as shown.
2
1
Attach each using two 3/4" (19 mm) screws as shown.
You have fi nished attaching your door trim.
63
BEGIN
Your door trim is now installed.
FINISH
Install WNA on lower section of door panel.
Secure from inside with 3/4" screws as shown.
1
WNA
5/8 x 4 x 14" (1,6 x 10 x 35,6 cm)
x8
WNA
3/4" (1,9 cm)
x18
PARTS REQUIRED:
DOOR TRIM
