STEP 6 - SWING BEAM ASSEMBLY
QTY
PART NUMBER
DESCRIPTION
2
H100005
NUT BARREL WH 5/16x7/8
2 H100016 BOLT WH 5/16x3
FULLY TIGHTEN ALL
016 BOLTS NOW.
005 (x2)
NUT BARREL - 7/8"
016 (x2)
BOLT - 3"
28
