STEP 4 - FORT ASSEMBLY
TIP:
INSTALL T-NUTS IN WOOD FIRST
074 (x8)
T-NUT - 5/16"
030 (x8)
WASHER - 8x19
019 (x8)
BOLT - 3 3/4"
G01 (x1)
H05 (x1)
QTY
PART NUMBER DESCRIPTION
8 H100019 BOLT WH 5/16x3 3/4
8 H100030
WASHER LOCK EXT 8x19
8 H100074 T-NUT 5/16
WALL RAIL - W4L16137
1"x3 3/8"x44 7/8" (24x86x1141)
H05
(x1)
GROUND RAIL - W4L16128
1"x5 1/4"x44 7/8" (24x134x1141)
G01
(x1)
