STEP 11 - FORT ASSEMBLY
QTY
PART NUMBER DESCRIPTION
1
H100008 BOLT WH 5/16x1
8 H100011
BOLT WH 5/16x1 3/4
9 H100030 WASHER LOCK EXT 8x19
9 H100074
T-NUT 5/16
TIP:
INSTALL T-NUTS IN WOOD FIRST
CROSS BRACE - W4L16133
1"x5 1/4"x64 5/8" (24x134x1642)
G04
(x2)
030 (x9)
WASHER - 8x19
011 (x8)
BOLT - 1 3/4"
008 (x1)
BOLT - 5/16x1"
074 (x9)
T-NUT - 5/16"
G04 (x2)
