STEP 12 - FORT ASSEMBLY

QTY

PART NUMBER DESCRIPTION

4 H100008 BOLT WH 5/16x1

H100016

BOLT WH 5/16x3

8 H100074 T-NUT 5/16

TIP:

INSTALL T-NUTS IN WOOD FIRST

ANGLE BRACE

BLK

(x2)

A4M01595

008 (x4)

BOLT - 5/16x1"

016 (x4)

BOLT - 3"

074 (x8)

T-NUT - 5/16"

595 (x2)

ANGLE BRACE BLK
