STEP 16 - FORT ASSEMBLY
TIP:
INSTALL T-NUTS IN WOOD FIRST
G06 (x1)
G05 (x1)
019 (x8)
BOLT - 3 3/4"
030 (x8)
WASHER - 8x19
074 (x8)
T-NUT - 5/16"
WALL RAIL - W4L16143
1"x5 1/4"x52 1/8" (24x134x1324)
G05
(x1)
WALL RAIL - W4L16144
1"x5 1/4"x52 1/8" (24x134x1324)
G06
(x1)
QTY
PART NUMBER DESCRIPTION
8 H100019 BOLT WH 5/16x3 3/4
8 H100030
WASHER LOCK EXT 8x19
8 H100074 T-NUT 5/16
44
