STEP 17 - FORT ASSEMBLY
TIP:
INSTALL T-NUTS IN WOOD FIRST
074 (x4)
T-NUT - 5/16"
030 (x4)
WASHER - 8x19
019 (x4)
BOLT - 3 3/4"
B05 (x1)
B05 (x1)
G01 (x1)
QTY
PART NUMBER DESCRIPTION
4 H100019 BOLT WH 5/16x3 3/4
4
H100030
WASHER LOCK EXT 8x19
4 H100074 T-NUT 5/16
UPRIGHT - W4L16139
3"x3"x24 3/4" (76x76x630)
B05
(x2)
GROUND RAIL - W4L16128
1"x5 1/4"x44 7/8" (24x134x1141)
G01
(x1)
