STEP 38 - FORT ASSEMBLY

BOTTOM VIEW

CORRECT BOARD ASSEMBLY

FRONT VIEW

ROOF CLEAT - W4L16172

5/8"x2 3/8"x37 3/8" (16x60x948)

N03

(x2)

22 1/4 in

[565

mm]

N03 (x2)

380 (x16)

SCREW - 1 1/8"

QTY

PART NUMBER DESCRIPTION

H100380 SCREW PFH 8x1 1/8 BLK

FLUSH (N03) WITH END OF ROOF PANEL
