STEP 44 - FORT ASSEMBLY
QTY
PART NUMBER DESCRIPTION
2
H100087 SCREW PFH 8x1-1/4"
TELESCOPE
(x1)
A6P00096
096 (x1)
TELESCOPE
087 (x2)
SCREW - 1-1/4"
TIP:
PILOT DRILL, IN DESIRED LOCATION,
USING A 1/8" (3 mm) DRILL BIT.
79
