CHAPTER 2 DISASSEMBLY AND REASSEMBLY OF MAJOR COMPONENTS1022H TRACTOR
2
NOTE
•
mat together.
3.4 SEPARATION OF THE FRONT AXLE BRACKET AND THE TRANSMISSION
Parts which can be inspected during This operation
- HST unit and pedal linkage
- Brake pedal and linkage
4. Remove the ROPS.
Remove the bolts which are tightened to 3P hitch.
5. Remove the oor panel seat.
The wiring of PTO is disconnected.
1. Drain the oil into the transmission case. (3.7 gal /
14 Liter)
2. Wedge both sides of the front axle to prevent the
engine from tilting.
3. Remove the seat assembly and the oor mat and
oor panel.
REMOVAL
0DW
)ORRU3DQHO
K19W036A
FIG. 2-17
3KLWFK
K19W037A
FIG. 2-18
K19W038A
FIG. 2-19
