5
-
21
OPERATION
5
CAUTION
•
Always check if there’s no in-
terference with the implement,
quick-coupler of the imple-
ment, and other attachments
when attaching to the 3-point
hitch to avoid fatal personal in-
jury or machinery damage.
1. To let the implement float along
contour of the ground, turn the
rectangular steel plate to the verti-
cal position.
2. To secure the implement, turn the
rectangular steel plate to the hori-
zontal position.
ADJUSTMENT OF VERTICAL
HEIGHT
(1) Rectangular steel plate
ADJUSTMENT OF CHECK BAR
1. For implements such as a plow
and disc harrow, adjust the length
so that it can be moved for 5 - 6
cm sideways.
2. For implements such as a rotary
tiller and mower, adjust the length
so that it cannot be swayed side-
ways.
(1) Stabilizer
4025h_4035h.indb 214025h_4035h.indb 21 2020-09-18 오후 6:23:182020-09-18 오후 6:23:18
