Bad Boy REBEL Series User Manual

PAGE 13
SECTION 8: MOVING INOPERABLE MOWER
8.1 Hopefully, you’ll never need to use this section of the manual. However, if you do, use extreme caution
when moving the mower! You should never try to push or pull the mower by hand. This could cause
serious bodily injury.
8.2 Do not tow the mower. Use a winch to load on a trailer for transporting.
Your Mower Weighs: REBEL SERIES: 1180-1310 lbs.
***Weights fluctuate with the addition of accessories.
8.3 If it becomes necessary to move an inoperable mower, the drive transaxles are equipped with bypass
valves that allow the drive tires to rotate freely. These bypass valves are located on top of the Rebel’s
transaxles. Each require a quarter turn to allow for proper bypass.
Neutral Bypass
Valve Access
Neutral
Bypass Valve
Neutral
Bypass Valve
Fig. 3
Fig. 5
Fig. 4

Bad Boy REBEL Series Specifications

General

Spindle Material	Cast Iron
Self-Propelled	Yes
Engine Options	Kawasaki
Cutting Width	61 inches
Engine Manufacturer	Kawasaki
Engine Type	Gasoline
Deck Material	Steel
Weight	Varies by model
Mulching Capability	Optional
Horsepower	22 HP, 23 HP, 27 HP
