Bad Boy REBEL Series User Manual

PAGE 30
BLADE REMOVAL
To change blades, it may be best to use a piece
of wood positioned between the blade and
mowing deck to keep the blade from turning. Use
a 15/16" socket and Bad Boy recommends an
impact wrench capable of and output torque of at
least 220 ft-lbs. A box wrench and extension can
be used, though component damage potential
may be increased. The bolt has right-handed
threads.
Re-torque the blade bolts to 90-110 ft-lbs. upon re-
installation.
The blade spindles contain a sealed bearing inside the
top and bottom of the spindle. The bearings are
replaceable for a more cost-effective repair. Factors such
as water introduction into the bearing will have a major
impact on bearing life.
Blade Bolts are Right
Hand Thread
Blade Stop
15/16” Socket
and Impact or a
Wrench with
and Extension
Fig. 45
Fig. 46

Bad Boy REBEL Series Specifications

General

Spindle Material	Cast Iron
Self-Propelled	Yes
Engine Options	Kawasaki
Cutting Width	61 inches
Engine Manufacturer	Kawasaki
Engine Type	Gasoline
Deck Material	Steel
Weight	Varies by model
Mulching Capability	Optional
Horsepower	22 HP, 23 HP, 27 HP
