Page 3 - 3
INTRODUCTION
Read all of this manual to become thoroughly familiar with this vehicle. Pay particular attention to all Notices, Cautions, Warnings, and Dangers.
3
FEATURES
1. State of Charge Meter/Fuel Gauge
Electric fuel gauge located on the left side of the dash panel, indicates the amount of charge remaining in the battery
pack when the key switch is in the ON position.
2. Brake Light
The indicator light illuminates to indicate that the parking brake is engaged when key switch is in the ON position.
3. Headlight Switch
Located on the dash panel to the right of the brake light. The switch has two positions, ON and OFF. In the ON posi-
tion the headlights and all dash panel lights will be on, the OFF position will turn off the lights.
4. Max Range/Max Speed
Two position switch located in the dash panel. The Max Range setting limits the top speed of the vehicle to 16 MPH,
saving battery power to extend the range of the vehicle when operated at full speed. The Max Speed setting allows
the vehicle to travel up to 24 MPH and sacrifices distance for speed.
5. Auxiliary Switch Positions
There is space for the addition of three rectangular toggle switches to control additional lights or accessories.
6. Winch Switch (if equipped)
Located in the driver side glove box.
3
4
5
2
1
6
