PAGE 23
FUEL FILTER
The fuel filter is located in the fuel line. Replace the filter
yearly. Prior to the removal of the old filter, note the
direction of fuel flow as indicated on the filter. Have
towels readily available in order to quickly remove any
fuel leakage. Always use new hose clamps and ensure
the security of the new filter by lightly pulling on each
hose. Always perform maintenance outdoors or in a well-
ventilated area. Do not smoke or allow any open flames
in the vicinity of any maintenance activities.
CHANGING YOUR FUEL FILTER
1. Locate your fuel filter and mark the direction it is
facing.
2. Clamp each side of the fuel filter to minimize any
gas spills.
3. Remove the clips from each side of the fuel filter
and remove the fuel filter.
4. Place the new fuel filter in the same direction as
the old and place clips back into place.
5. Remove clamps.
Fuel Filter
Verify Flow
Direction
Fuel Line
Clam
Fuel Line
Clam
Fuel Line
Cli
Fuel Line
Cli
