Badger Power Electronics BPE600 - Page 19

Installation/User Manual
18
.
Model
BPE1300-240V
Input Data (DC)
Operation Voltage Range 20V-55V
Startup Voltage
20V
Maximum DC Short Circuit Current
Output Data (AC)
Nominal Output Voltage 240V
Nominal Output Current
5.416A
Default/Protect Output Voltage Range
Nominal Output Frequency
Extended/Reconnect Output Frequency Range
50Hz/45-55,60Hz/59.3-60.5
Total Harmonic Distortion <3%
Efficiency
Night Power Consumption 50mW
Mechanical Data
Storage Temperature Range -40 °C to +85 °C
Weight
6.5kg
Enclosure Rating IP65
Wet Locations Classification For Wet Locations
Relative Humidity Ratings 0-95%
Certificates UL1741,VDE0126,VDE4105,IEC62109,CE
© All Rights Reserved
Pollution Degree Classification PD3
Communication
Powerline
Operating Ambient Temperature Range -40 °C to +65 °C
Max. Inverter Efficiency 96.5%
Power Factor >0.99
Default/Protect Output Frequency Range
50Hz/45-55,60Hz/59.3-60.5
Maximum Output Power 1300
W
Maximum Input Current
10.4A x4
MPPT Voltage Range 25V-55V
BPE1300 Microinverter Datasheet
Maximum Input Voltage 60V
Extended/Reconnect Output Voltage Range
184-265V
Dimensions (W x H x D)
450mm X 455mm X 35mm
Cooling Natural Convection - No Fans
Maximum Altitude Rating All Data At This Technical Specifications Has Been Tested Under <2000m
13A
184-265V
50Hz/60Hz Auto Sense
