Badger Power Electronics BPE600 - Page 22

Installation/User Manual
21
Sample Wiring Diagram Three Phase
Sample Wiring Diagram BPE1300
MAX 4 BPE1300
BLACK L2 RED L1 YELLOW NEUTRAL
JUNCTION BOX
METER
ETHERNET CABLE
TO BROADBAND ROUTER
GROUND
MAX 4 BPE1300
MAX 4 BPE1300
