Badger Power Electronics BPE600 - Page 23

Installation/User Manual
22
Sample Wiring Diagram Single Phase
Sample Wiring Diagram BPE1300
MAX 4 BPE1300
BLACK L2 RED L1 YELLOW NEUTRAL
JUNCTION BOX
METER
ETHERNET CABLE
TO BROADBAND ROUTER
GROUND
MAX 4 BPE1300
MAX 4 BPE1300
