G200 is a new designed Smart Wireless Gate controller. It could be well inte-
grated with most of the electronic locks, gate motors, gate operators, and
widely used in residential, institutional, industrial markets. G200 works with a
Nano SIM card, users could dial the SIM card number to open the door, and no
phone charges, no distance limits, no keyfobs, more convenient and friendly
than any other solutions.
GSM/3G Gate Controller
Page 2
Introduction
Specifications
GSM/3G Frequency
GSM: Quad-band 850/900/1800/1900MHz
3G WCDMA : 900/2100 MHz UMTS
3G CDMA2000: 850/1900 MHz UMTS
DC Power DC 9V – 36V /1A
Power consumption Max. 50mA/Average 25mA
SIM Card Nano type, 3V
Antenna 50 Ω SMA
Relay Specification 3A/250V AC | 20A/14V DC
Relay Type NO/NC
Relay Time Max. 0s - 900s
Users 200
Wired Switch Supports
Operating Temp
- 10℃ ～ + 60℃
Relative Humidity
10％ ～ 90％( RH)
Dimension 96.5×50×31.5mm
Net Weight 88g
