Interface Module XC Modbus
Protocol Converter / User Manual
Page 7 from 10
E120103819092
Baer Energie- & Messtechnik GmbH  Siemensstr. 3  D-90766 Fürth  Phone +49 911 970590  Fax +49 911 9705950
Example for read out meter data:
Service data TS (/4! with completion character CR LF):
/EMH4\@\201LZQJL001VE
0.0.1(00000123) Address/Start register: 0, Value: 123
1.25(0.00*kW) Address/Start register: 2, Value: 0
3.25(0.00*kvar) Address/Start register: 4, Value: 0
9.25(0.00*kVA) Address/Start register: 6, Value: 0
31.25(0.02*A) Address/Start register: 8, Value: 2
51.25(0.01*A) Address/Start register: 10, Value: 1
71.25(0.01*A) Address/Start register: 12, Value: 1
32.25(0.59*V) Address/Start register: 14, Value: 59
52.25(0.50*V) Address/Start register: 16, Value: 50
72.25(246.07*V) Address/Start register: 18, Value: 24607
13.25(0.00*P/S) Address/Start register: 20, Value: 0
14.25(50.01*Hz) Address/Start register: 22, Value: 5001
C.86.0(38307030) Address/Start register: 24, Value: 38307030
C.86.6(B05800F0) Address/Start register: 26, Value: 58000
Modbus registers:
Register
address
Value
Comments
0
0
OBIS-Register 0.0.1: 123 (:= 0 + 123, Modbus ID-Address)
1
007F
Hex
(:= 0123
Dec
)
2
0
OBIS-Register 1.25: 0 kW (:= 0 + 0)
3
0
4
0
OBIS-Register 3.25: 0 kvar (:= 0 + 0)
5
0
6
0
OBIS-Register 9.25: 0 kVA (:= 0 + 0)
7
0
8
0
OBIS-Register 31.25: 0.02 A (:= 0 + 2)
9
2
10
0
OBIS-Register 51.25: 0.01 A (:= 0 + 1)
11
1
12
0
OBIS-Register 71.25: 0.01 A (:= 0 + 1)
13
1
14
0
OBIS-Register 32.25: 0.59 V (:= 0 + 59)
15
003B
Hex
(:=59
Dec
)
16
0
OBIS-Register 52.25: 0.50 V (:= 0 + 50)
17
0032
Hex
(:=50
Dec
)
18
0
OBIS-Register 72.25: 246.07 V (:= 0 + 24607)
19
601F
Hex
(:=24607
Dec
)
20
0
OBIS-Register 13.25: 0 P/S (:= 0 + 0)
21
0
22
0
OBIS-Register 14.25: 50,01 Hz (:= 0 + 5001)
23
1389
Hex
(:=5001
Dec
)
24
0248
Hex
(:= 584
Dec
)
OBIS-Register C.86.0: 38307030 (:= (584 × 65536) + 34006)
25
84D6
Hex
(:= 34006
Dec
)
26
0
OBIS-Register C.86.6: 58000 (:= 0 + 58000, characters B and
F will be clear in the string B05800F0)
27
E290
Hex
(:= 58000
Dec
)
28
FFFF
Hex
(:= 65535
Dec
)
Not used registers
29
FFFF
Hex
(:= 65535
Dec
)
...
FFFF
Hex
