Motor Installation Continued
The bottom bracket lock ring should now be
threaded on to the motor axle.
This lock ring should be tightened to 50-60
Nm of torque using the bottom bracket lock
ring tool as shown to the right in photo 2.
Now the Bafang lock ring can be threaded
on to the motor axle.
This lock ring should be tightened to 25-30
Nm of torque using the 8FUN lock ring tool
as shown in photo 4 of this page.
The motor installation is now complete.
