6.3.3.3 Connection of the gear sensor to the motor
The male connector from the
motor
The female connector from the
gear sensor
A
a
Please connect the connectors from the motor and the gear sensor together.
6.3.3.4 Connection of the speed sensor to the motor
The female connector from
the motor
The male connector from the
speed sensor
A
a
Please connect the connectors from the motor and the speed sensor together.
6.3.3.5 Connection of the communication to the motor
The female connector from
the battery BMS
The male connector from the
motor
A
a
Please connect the connectors from the motor and the battery BMS together.
